Results and current approach for Brachial Plexus reconstruction
© Bertelli and Ghizoni; licensee BioMed Central Ltd. 2011
- Received: 4 January 2011
- Accepted: 16 June 2011
- Published: 16 June 2011
We review our experience treating 335 adult patients with supraclavicular brachial plexus injuries over a 7-year period at the University of Southern Santa Catarina, in Brazil. Patients were categorized into 8 groups, according to functional deficits and roots injured: C5-C6, C5-C7, C5-C8 (T1 Hand), C5-T1 (T2 Hand), C8-T1, C7-T1, C6-T1, and total palsy. To restore function, nerve grafts, nerve transfers, and tendon and muscle transfers were employed. Patients with either upper- or lower-type partial injuries experienced considerable functional return. In total palsies, if a root was available for grafting, 90% of patients had elbow flexion restored, whereas this rate dropped to 50% if no roots were grafted and only nerve transfers performed. Pain resolution should be the first priority, and root exploration and grafting helped to decrease or eliminate pain complaints within a short time of surgery.
Brachial plexus lesions are a tragic condition that usually affects young adults, with significant socioeconomic implications. Only four decades ago, brachial plexus surgery still was approached with considerable pessimism. As recently as the 1996 International Society for Orthopaedic Surgery and Traumatology (SICOT) in Paris, it was concluded that surgical repair of these lesions was almost impossible and, even when performed, did not guarantee a useful result . However, the ongoing increase in the number of civilian brachial plexus lesions due to motorcycle accidents has, without a doubt, promoted interest in this field, and recent years have witnessed tremendous progress in surgical techniques for brachial plexus repair. At our institution, between January 2002 and December 2008, 335 patients suffering from supraclavicular brachial plexus palsy underwent surgical repair. In the present report, we review our results and current approach to treatment. Written informed consent were obtained from patients for publication of clinical cases and accompanying images. In advance of any data collection, the protocol of the present study was approved by the local ethics committee. All patients provided their written informed consent prior to their participation, in accordance with the Declaration of Helsinki guiding biomedical research involving human subjects.
Diagnosing brachial plexus palsies
In half of our patients, electrophysiological studies were available preoperatively. In 102 patients, magnetic resonance imaging (MRI) of the brachial plexus, including the spinal cord, was obtained, whereas computed tomomyelography (CT myelography) was performed in all cases. The clinical diagnosis of root involvement was correct in 85% of our patients. Extremely reliable tests or signs were a supraclavicular Tinel's sign to indicate a graft-able root, and a Horner's sign to indicate lower root avulsion . Electrophysiological studies did not contribute, in any way, to identifying indications for surgery or to surgical planning. Consequently, we no longer request electrophysiological studies preoperatively. MRI was useful merely to document avulsion of the lower roots. However, Horner's sign was 96% predictive of lower root avulsion . MRI was not helpful in identifying a graft-able root at the C5 or C6 level, because of poor visualization of the intradural portion of these roots. This is the main reason for interest in CT myelography: confirming that a root stump located in the supraclavicular region during dissection is in continuity with the spinal cord and, thereby, eligible for grafting.
Timing of surgery
Patients with total palsy of the brachial plexus following a traffic accident have almost no chance of spontaneous recovery. In our series of patients with total palsy, spontaneous recovery was not observed. This is different for partial injuries, in which some spontaneous improvement might occur. We prefer to operate on such patients after the third month but before the sixth month after injury. Some of our patients were operated upon after the seventh month with good results. However, more than 9 months after trauma, our results declined dramatically.
In partial injuries, we observed some good results even 10 months after surgery when distal nerve transfers were employed. This was not observed in patients with total palsy in whom nerve grafts were used 10 months or more following the accident .
Definition of paralysis according to root involvement
C5-C6 root injury (n = 54)
Grasping, pinch and wrist and elbow extension strength in the different group of palsies.
Type of palsy
Wrist extension (Kg)
Elbow extension (Kg)
26.3(95% CI, 22.9-29.7)
8 (95% CI, 7.1-8.8)
7.1(95% CI, 6.1-8.1)
7.8 (95% CI, 6-9.5)
14.7(95% CI, 8.7-20.7)
6(95% CI, 4.8-7.1)
5.6 (95% CI, 5.1-6.2)
4.8(95% CI, 4.2-5.4)
13(95% CI 9.7-16.3)
4(95% CI 2.8-5.3)
paralyzed or extremely weak
paralyzed or extremely weak
38(95% CI, 36.6-39.4
10.1(95% CI, 9.2-10.9)
13(95% CI, 11.4-14.5)
11.8 (95% CI, 10.4-13.2)
C5-C7 root injury (n = 18)
The clinical picture with this lesion was similar to what we observed in the C5-C6 palsy group. Wrist, finger and elbow extension were preserved, but there tended to be a greater loss of strength than in the C5-C6 patients (Table 1). The upper portion of the pectoralis was atrophied. The latissimus dorsi was paralyzed in half of the patients. The flexor carpi radialis and pronator teres were paralyzed. There was an extended sensory deficit, but no loss of protective sensation in the fingers. Hand grasp strength was just 39% that observed in the normal contralateral limb, whereas pinch strength was 60% the normal value. Wrist extension and triceps strength were 43% and 41% that of the normal side, respectively. Relative to the C5-C6 group, grasp, pinch, triceps and wrist extension strength were significantly decreased. There was a reduction in sensation in all fingers, but especially in the thumb. However, protective sensation was preserved throughout the entire hand. There was a continuous longitudinal area of anesthesia along the lateral aspect of the forearm and arm, and over the deltoid chevron (Figure 1).
C5-C8 root injury (T1 Hand, n = 63)
In addition to the shoulder and elbow flexion palsy, the teres major, latissimus dorsi and triceps all were paralyzed. The pectoralis major was paralyzed. Wrist extension was paralyzed in all patients. However, some patients could extend their wrist with the help of thumb and finger extensors. In these cases, wrist extension strength did not exceed 1 kg. In a few patients, only extension of the thumb and index finger was preserved. The triceps, flexor carpi radialis, pronator teres and flexor carpi ulnaris were paralyzed. Wrist flexion was possible, thanks to the palmaris longus. Pronation was possible because the pronator quadratus functioned. Hand grasp strength was 36% that of the normal side, and pinch strength 40% of normal (Table 1). In comparison with the C5-C6 ± C7 groups, grasping and pinch strength were significantly reduced. There was a continuous longitudinal zone of lost protective sensation over the lateral forearm, lower arm and deltoid chevron, as in the previous group. However, this region was wider, affecting 1/3 of the limb circumference. Contrary to the previous group, the dorsal aspect of the hand, including the dorsal ulnar side, now was affected. With respect to the fingers, there was no particular pattern of sensory disturbance. For instance, a few patients presented with thumb anesthesia, but others exhibited normal sensation in all fingers. In no instance was complete anesthesia of all fingers observed (Figure 1). Horner's sign was absent.
C5-T1 root injury with partially preserved finger flexion and Horner's sign (T2 Hand, n = 12)
In these patients, the shoulder was completely paralyzed. Adduction was impossible, because the pectoralis major was totally paralyzed in all patients. Finger and wrist extension were paralyzed. Wrist flexion was weak, but preserved in half of the patients because the palmaris longus remained functional. Finger flexion was noted in all cases, but it was incomplete in excursion, and in no hand were all fingers functional. Grasping and pinch strength were not measurable due to extreme weakness. Thumb anesthesia was frequent. The dorsal aspect of the hand was completely anesthetized. The lateral longitudinal bundle, over the forearm and arm, was wider, now comprising 2/3 of the limb circumference (Figure 1). There was a zone of normal sensation over the ulnar border. It is our impression that these patients had either an undetected partial root injury of T1, though CT tomomyeloscans confirmed avulsion; or, more likely, post-fixation of the brachial plexus by T2. We now call this cohort of patients the T2 hand group.
C8-T1 root injury (n = 9)
Values of strength for elbow flexion/extension and wrist extension in C8-T1 and C7-T1 palsies.
Type of palsy
16.2(95% CI, 13.5-18.9)
12.5 (95% CI, 7.9 17)
9.5(95% CI, 6.7-12.2)
11.6 (95% CI, 10.6-12.6)
6(95% CI, 3.6-8.3)
13(95% CI, 11.4-14.5)
C7-T1 root injury (n = 22)
These patients with more extensive palsy recovered spontaneously in the territory of the upper roots of the brachial plexus. Shoulder and elbow range of motion were normal. However, strength was markedly reduced relative to the patient's normal side, and relative to the affected limb in the C8-T1 palsy group (Table 2). For instance, elbow flexion strength was 61% and triceps strength just 25% that of the normal side. Wrist extension was weak, corresponding to 46% that of the normal side. When patients extended their wrist, radial deviation occurred. Both the extensor carpi radialis brevis and longus functioned, but the extensor carpi ulnaris was paralyzed. Sensory disturbance was present along the ulnar aspect of the hand, forearm and arm. As opposed to the C8-T1 group, decreased sensation also was apparent in the third finger. Thumb sensation was normal.
C6-T1 root injury (n = 4)
We observed 4 patients with paralysis of finger flexion/extension, accompanied by weak wrist extensors and triceps paralysis. Triceps paralysis and weak wrist extension were the main differences in this versus the previous group. Shoulder motion and elbow flexion were almost normal. Surgery was not performed for brachial plexus exploration; hence, the status of the roots was not inspected directly. On CT myeloscan, avulsion of C7-T1 was confirmed in all cases. The nature of the lesion affecting C6 was not clear. Most likely, there was partial injury with spontaneous recovery. Of importance is that, in this group of patients, elbow extension reconstruction is mandatory.
Total Palsy (n = 168)
In these patients, the clinical picture was a flail limb. All patients presented with a Horner's sign. The sensory deficit included the entire limb, except for the inner aspect of the arm.
Upper Type Palsies (C5-C6 ± C7)
Our overall results for reconstruction of upper-type lesions of the brachial plexus are encouraging. Both full abduction and full external rotation of the shoulder were restored in 15% among those in the C5 and C6 nerve root avulsion group reconstructed by triple nerve transfer, in 67% of the patients who received C5 nerve root grafting plus a triple nerve transfer, and in 33% of patients who received a C5+C6 nerve root graft group, plus transfer of cranial nerve XI to the suprascapular nerve and ulnar nerve fascicles to the biceps motor branch. The average percentages of elbow flexion strength recovery, relative to the normal, contralateral side, were 27%, 43% and 59% for the C5-C6 nerve root avulsion, C5 nerve root graft, and C5+C6 nerve root graft groups, respectively. Hence, it seems that combining grafted roots with distal nerve transfers also improves elbow flexion strength.
When the C5 root was available for grafting, it was grafted either to the anterior or posterior division of the upper trunk. To date, we have not observed clear differences in recovery of motion attaching nerve grafts to the anterior versus posterior division of the upper trunk, but this may be because of the few patients like this that we have had. In the 'T1 hand' group of patients, elbow extension has required reconstruction. In a few patients, we have used the median nerve to neurotize the biceps motor branch, while ulnar nerve fascicles were used to neurotize the triceps long head motor branch. None of these patients recovered satisfactory elbow flexion/extension. Consequently, we have abandoned the procedure of triceps reinnervation by ulnar nerve fascicles.
In another group of 4 patients, we tried intercostal nerve transfers to the triceps long head motor branch, with fruitless results, either because of poor reinnervation or poor motor control. Our current approach is to transfer the levator scapulae motor branch to the triceps long head motor branch, aided by a sural nerve graft. Recovery of elbow extension is not strong, but is fully under voluntary control, and control over elbow flexion-extension is important to stabilize the elbow when tendon transfers are needed for thumb and finger extension reconstruction. In this regard, we should highlight an important point. If the motor fascicles of the flexor carpi ulnaris (FCU) are transferred for elbow flexion through biceps reinnervation, and then the FCU is transferred to the extensor digitorum communis (EDC) and extensor pollicis longus (EPL) for reconstruction of a radial nerve palsy, results will be very poor. When the patient extends the thumb and fingers by activating the transferred FCU, the elbow flexes concomitantly. In the T1 hand, ulnar nerve fascicles to the intrinsic muscles of the hand should be used for finger flexors instead of fascicles for the FCU, as originally proposed by Oberlin et al. Transferring fascicles of the ulnar nerve to the intrinsic muscles of the hand does not downgrade hand fucntion .
Another interesting observation we have made is that, in general in the T1 hand, intra-operative electrical stimulation of the median nerve produces stronger finger motion than stimulation of the ulnar nerve. Hence, in the T1 hand, we always dissect both the ulnar and median nerves, stimulate them with a nerve locator, and then use the 'stronger' nerve as a donor of fascicles for biceps reinnervation.
A) With graft-able roots
In 87% of our patients with total palsy, a graft-able root was available.2 In these patients, the accessory nerve is always transferred to the suprascapular nerve, which yields an average of 57° of shoulder abduction. When two roots were available for grafting, typically C5+C6, C5 was grafted to the anterior division of the upper trunk, and C6 was grafted to the posterior division. Sural grafts were less than 10 cm long. After surgery, forearm muscle reinnervation was not useful. Some patients recovered wrist flexion and some finger flexion, albeit weak. We consider M3-level finger flexion useless, because our patients did not use their hand for active grasping. Elbow flexion/extension could not be restored simultaneously. Elbow flexion was M3 or more in 85% of these patients. Elbow flexion always was accompanied by pectoralis major contraction .
In a second group of patients, the C5 root was grafted more distally, either to the lateral cord or to the musculocutaneous nerve. When available, the C6 root was grafted to the radial nerve. The pectoralis major was reinnervated by branches to the platysma, whereas the triceps long head was reinnervated by branches to the levator scapulae nerve. Elbow flexion scoring M3 or better was identified in 91% of patients, a score slightly better than when short grafts were connected to the upper trunk [8, 9]. These findings might result from double lesions of the musculocutaneous nerve, which occurred in 18% of our cases  and would have been passed undetected when only the supraclavicular region of the brachial plexus was explored. Transferring the levator scapulae motor branch to the triceps long head restored elbow extension predictably, albeit weakly. Using the C6 root to reconstruct the radial nerve largely was unpredictable, both with respect to elbow extension and wrist and finger extension. Though partially successful, definitive conclusions regarding the transfer of the platysma motor nerve to the medial pectoralis nerve cannot be drawn.
In a third group of patients, we grafted the C5 root to the lateral cord using a vascularized ulnar nerve graft. Results were poor. In our opinion, the reasons for failure are related to the length of our grafts allied with the unfavorable internal morphology of a trunk graft. It is possible that regeneration in long, vascularized trunk grafts is worse than what occurs after the same repair using a sural nerve graft. We have since abandoned the use of vascularized ulnar nerve grafts. In total palsies, our current trend is to graft roots and donor nerves directly to recipient nerves using longer grafts.
In total palsies of the brachial plexus, it is imperative to graft viable roots. This offers not only a good potential for recovery, but also treats brachial plexus pain. In total lesions, 84% of the patients suffered from pain and almost 84% have a graft-able root[2, 11]. Pain subsided in half of these patients in the days after grafting. We have postulated that pain in brachial plexus injuries stems from ruptured rather than avulsed roots, challenging current concepts which blame deafferentation as the origin of pain. In patients who have been grafted but pain persists, we have attributed pain to the growth of axons, because this process is associated with the large production of neurotrophic factors that produce pain[14, 15].
B) Without graft-able roots
In these patients, not only are there no roots available for grafting, but donor nerves for transfer - like the accessory and phrenic nerve - may not be available either. After surgery, only half of these patients achieved recovery of elbow flexion when we used the phrenic nerve, contralateral C7 or hypoglossal nerve. For suprascapular nerve neurotization, we used the accessory nerve, contralateral C7, hypoglossal nerve, cervical plexus and platysma motor branch. Shoulder abduction was restored in half the patients, to an average of 28°. Results for reconstruction of total palsies without a graft-able root clearly were worse than when a root was eligible for grafting. This suggests that root grafting is better than extraplexual nerve transfers for elbow flexion reconstruction. Extension of the trauma also may have affected donor nerves for transfer. For instance, results for shoulder abduction following cranial nerve XI to suprascapular nerve transfers were poor, relative to when a root was available for grafting. This might reflect not only an associated lesion of the accessory nerve, but also an extended lesion affecting the suprascapular nerve.
Lower Type Palsies
In all patients, thumb and finger flexion was reconstructed by transferring the brachialis muscle to the flexor digitorum profundus and flexor pollicis longus. Tension was adjusted according to each patient's needs. Restoration of at least 2 kg of grasping strength allowed our patients to use their hand during daily activities. Some patients recovered up to 8 kg of strength, because more tension was applied during the transfer. This augments the power of grasping when the elbow is extended as a consequence of a tenodesis effect. In addition, strong wrist extension is helpful to increase the range of motion and power of finger flexion. However, when more tension is applied for the brachialis transfer, hand span may be jeopardized. It is particularly important to reconstruct thumb motion, more than that of the fingers. In two patients, besides a brachialis transfer, during a second surgery we transferred the brachioradialis to the flexor digitorum superficialis and flexor pollicis longus. These two patients experienced a 50% improvement in grasp strength, with preserved hand span.
When paralyzed, elbow extension was reconstructed by transferring the posterior deltoid to the triceps using a fascia lata graft. All 4 patients recovered enough stability of the elbow to allow us to proceed to tendon transfers for hand reconstruction. Only one patient recovered M4 elbow extension, with the remaining scoring M3-. If surgery is performed within 6 months of injury, we now prefer to reconstruct elbow extension by transferring either the motor branch of the posterior deltoid or the motor branch of the teres minor, as we have done for tetraplegics[17, 18].
Finger extension, when absent, was successfully reconstructed by transferring the supinator motor branches to the posterior interosseous nerve[19, 20]. Tenodesis of the EDC and EPL produced poor results. Poor outcomes also resulted from transferring the extensor carpi radialis longus or brachioradialis to the EDC.
Thumb stabilization by tenodesis of the abductor pollicis longus on the dorsal side of the radius or to the FCU produced limited improvement. In contrast, excellent results for thumb stabilization and spanning occurred after transferring the supinator motor branch to the posterior interosseous nerve. Good results also were observed in two patients with chronic lesions who had their supinator muscle transferred to the extensor pollicis brevis, aided by a tendon graft . In addition, in 3 patients with longstanding lesions, thumb and finger extension were successfully reconstructed by transferring a free gracilis muscle reinnervated by the supinator motor branch. Free muscle transfer is our preferred method of reconstruction of thumb and finger extension in patients with lower type palsy of the brachial plexus lasting for more than 12 months. When needed, stabilization of the thumb interphalangeal joint was achieved by transferring half of the flexor pollicis longus to the extensor pollicis longus.
In partial injuries, brachial plexus surgery is highly rewarding. In total palsies, motion of the shoulder and elbow can be predictably reconstructed, provided that a root is available for grafting. If no root is available, only half of the patients will experience improved motion. Useful reconstruction of hand function is not yet possible with total lesions. Finger flexion or wrist extension scoring M3, although reconstructed in a few cases, was not much appreciated by our patients. Thoracobrachial and forearm abdominal grasping was their preferred method for holding objects. Treatment of pain should be a first priority. In this regard, roots should be explored and grafted.
